TLV Pressure Reducing Valve GP-1000 & GP-2000 - Pilot Operated Piston Type

TLV Pressure Reducing Valve - Pilot Operated Piston Type

Premium Japanese-engineered pressure reducing valves designed for precise steam pressure control in industrial applications. Available in GP-1000 and GP-2000 series models with ductile cast iron construction and JIS 10K FF flanged connections.

Key Features

• Pilot Operated Piston Type: Advanced piston mechanism for precise and reliable pressure control
• Wide Pressure Range: Inlet pressure 0.1-1.0MPa, reduced pressure 0.05-0.9MPa
• High Reduction Ratio: Maximum pressure reduction ratio of 20:1 for versatile applications
• Adjustable Pressure: Set reduced pressure up to 90% or less of inlet pressure (gauge pressure)
• JIS 10K FF Flanged: Standard Japanese industrial flanged connections for easy installation
• High Temperature Rated: Maximum operating temperature of 220°C for demanding steam applications
• Low Differential Pressure: Minimum differential pressure of only 0.05MPa

Material Construction

• Body: Ductile cast iron for superior strength and durability
• Valve & Valve Seat: Stainless steel for corrosion resistance and long service life
• Piston & Cylinder: Brass or bronze for smooth operation

Applications

Ideal for steam system pressure regulation, industrial process control, boiler feed systems, HVAC steam applications, and any application requiring precise downstream pressure control. Perfect for facilities requiring reliable pressure reduction with minimal maintenance.

Available in Karachi for immediate delivery to industrial and commercial customers across Pakistan.
